2010 Special Fabrication Category Entries


Fabricated Project of the Year
Steel Fabricated Products
Special Fabrication Category



Entry #1

Product Description:       (6) Tanks – 18’ Cylinder with a Cone Bottom on Legs used for Red Wine Fermentation
Owner:                                 Diageo Chateau & Estates: Blossom Hill Winery
Location of Product:        Paicines, CA
Date of Completion:         November 19, 2010
Date of Operation:            December 17, 2010
Overall Height:                   29’ – 10”
Overall Length:                  18’ – 0”
Diameter:                            14’ – 6”
Capacity or Flow:              25,000 Gallons

Special Features:
There are (6) of these tanks that are used for red wine fermentation. There is an (18’) cylinder with a cone bottom on legs.
The offset cone bottom combined with a pneumatic activated bottom manway allows for a self-emptying tank. This saves time, manpower and eliminates the need for permitted tank entry.


Fabricated Project of the Year
Steel Fabricated Products
Special Fabrication Category



Entry #2

Product Description:       Advanced Energy Recovery and Multi-Pollutant Emission Control Units for Power and
                                  Industrial Applications
Owner:                                Eco Power Solutions (USA) Corp.
Location of Product:        Louisville, KY
Date of Completion:         June, 2010
Date of Operation:            August, 2010
Overall Height:                   6’ – 6’ Square
Overall Length:                  30’ – 0”
Diameter:                            N/A
Capacity or Flow:              15,000 CFM


Special Features:



Advanced Energy Recovery and Multi-Pollutant Emission Control Units for Power and Industrial Applications that utilize Coal, Oil or Gas as the Fuel Source. The units remove up to 98% of combustion emission pollutants (NOx, SOx, Hg, Particulate PM2.5) as well as up to 25% of CO2. The system received the 2010 Most Promising Energy and Clean Technology Award at the 8th Annual Rice Alliance Energy and Technology Venture Forum.

Two Energy Recover and Multi-Pollutant Emissions Control Systems (one for Coal and one for Gas/oil) were Fabricated and Installed at a facility in Louisville, KY. Both include heavy carbon structural steel tubing for structural integrity with powder coated carbon exterior steel. The Coal unit has Inconnel 286 interior steel for all gas-path surfaces and the Gas unit contains 316 SS interior. Both units are insulated with 4” of mineral wool in order to optimize energy recovery and maintain a safe work environment exterior to the unit and have specially fabricated man-doors for access. Internal to the units are Herasite coated 304 Stainless Steel tubing and spray nozzles to ensure hydrolysis required for the emissions reduction. Downstream of the spray are energy recovery coils that are manufactured from Herasite coated copper tubing, aluminum fins and stainless steel structure.


Fabricated Project of the Year
Steel Fabricated Products

Special Fabrication Category



Entry #3

Product Description:       Infinite Room
Owner:                           Pieso’s Private Residence
Location of Product:      Eastern WA
Date of Completion:      September, 2010
Date of Operation:        N/A
Overall Height:             22’ – 0”
Overall Length:             22’ – 0”
Diameter:                     17’ – 0”
Capacity or Flow:            N/A

Special Features:

Design, fabricate, deliver & erect onsite a 17’ diameter x 22’ high steel “Infinite Room” and a 5’ diameter x 18’ 6” high stair column, and 18” diameter pipe for chimney flue.

Set in a rocky and forested site near the Spokane River, the focus of this home is the site surrounding it. The client wanted a house that is in dialogue with the elements of earth, wind, water and fire, and the architecture responds by blurring the boundaries between inside and outside through materials, contrast and art.
The owner commissioned a site-specific art installation for her home. The artist conceived of an infinite room a kind of meditation space that is centered on a line drawn by connecting two mountain peaks visible from the site. The architectural team took information on the shape and dimensions of the bowl and developed the concept into architecture. Midway through construction, the half-completed infinite room is in dialogue with the entrance tower, resulting in a unique architectural conversation.

Fabricated Project of the Year
Steel Fabricated Products

Special Fabrication Category



Entry #4

Product Description:       Sculpture
Owner:                           Kevin Box – Artist
Location of Product:       Michigan
Date of Completion:       July, 2010
Date of Operation:         N/A
Overall Height:               16’ – 0”
Overall Length:                8’ – 0”
Diameter:                         N/A
Capacity or Flow:             N/A

Special Features:

Boat is made out of 3/16” coated stainless steel.


WINNER

Brown-Minneapolis Tank – Northwest
www.bmt-tank.com

Fabricated Project of the Year
Steel Fabricated Products
Special Fabrication Category





Product Description:       Intake Structure for Public Water System
Owner:                                City of Las Vegas
Location of Product:        Boulder City, NV
Date of Completion:         December, 2010
Date of Operation:            N/A
Overall Height:                   N/A
Overall Length:                  N/A
Diameter:                            16’ – 0”
Capacity or Flow:              N/A


Special Features:



Intake structure for public water system made from stainless steel 2.5 Molybdenum special blend. Steel fabrication with machined 16’ diameter ID bolting flange. Overall shipping diameter was 18’ 9”, which was a challenge to ship.

Entry #5



Fabricated Project of the Year
Steel Fabricated Products
Special Fabrication Category



Entry #6

Product Description:       African Symbols
Owner:                                Kevin Box – Artist
Location of Product:        Albuquerque, NM
Date of Completion:         November, 2010
Date of Operation:            N/A
Overall Height:                   8’ – 0”
Overall Length:                  8’ – 0”
Diameter:                            N/A
Capacity or Flow:              N/A


Special Features:



African symbols for the African American Performing Arts Center.


Entry #7

Product Description:       Mercury Guard Bed
Owner:                                Questar Gas Management
Location of Product:        Granger, WY
Date of Completion:         December, 2010
Date of Operation:           N/A
Overall Height:                   20’ – 0”
Overall Length:                  N/A
Diameter:                            156” ID x 5 ¼” Thick
Capacity or Flow:              N/A


Special Features:



156” ID x 20’-0” S/S x 5.25” Thick – Mercury Guard Bed made of 516-70 Carbon Steel.
