Roberto R. Bustamante Headworks
Roberto R. Bustamante Headworks
El Paso, TX, United States
ROBERTO R. BUSTAMANTE WASTEWATER HEADWORKS
(6) Identical pieces for this project.
Each piece is a Square to Round, Offset Reducing 49 1/4″ OD down to 31 1/4″ OD 90 Degree (11 pc) Mitered Flanged Elbow, with a 26″ Saddled Outlet, also (6) 3″x3″x3/8″ Annular Stiffening Rings. We had to put a Blind Flange on, with angle iron welded to the inside of the Blind Flange and the saddle cut out welded to the bottom of the angle iron to create a smooth flow.
Each piece is rated for 200 PSI Test.
Coated with a C210 Liquid Epoxy Primer and Lined with 80 Mils of C222 Polyurethane.
Rinconada Water Treatment Plant
Rinconada Water Treatment Plant
Los Gatos, California, United States
Pipe fabricated per AWWA C200
Outlets designed per M11
Flanges per AWWA C207
Fabricated elbows per AWWA C208
Epoxy coating per AWWA C210
Cement mortar lining per AWWA C205
Richfield Water Tower
Richfield Water Tower
Richfield, Ohio, United States
In 2022, the City of Cleveland contracted for a new 1,000,000 gallon “All-Steel”, single-pedestal spheroid style tank which is one of the tallest spheroid tanks ever built. Towering above the horizon, this tank extends 234′-6 above it’s base foundation.
Winner
Dismantle and Re-Erection of two 75’-5 Dia x 250psig Spheres
Dismantle and Re-Erection of two 75’-5 Dia x 250psig Spheres
Cuenca, Cuenca, Ecuador, Ecuador
Engineer, Dismantle, Transport, and Re-Erection of (2) 75’-5 Dia x 250psig LPG Spheres in Ecuador. The spheres were dismantled and re-erected more than 300 km away at another LPG facility. Reconstructed spheres were designed to match the original design of ASME Section VIII, Div 2.
Oscar Renda
Oscar Renda
Carrington, North Dakota, United States
Pipe fabricated per AWWA C200
Tee fabricated per AWWA C208
Crotch plate reinforcement per M11
Flange per AWWA C207-18
Coating per AWWA C222
Lining per AWWA C205
Button Road Water Storage Tank
Button Road Water Storage Tank
Halfmoon, New York, United States
The Button Road Water Storage Tank is a 1,000,000-gallon, all-steel and all-welded, fluted column elevated water storage tank for the Town of Halfmoon, NY. The municipality selected the Hydropillar due to pleasing aesthetics and its reliable all-steel design.
